| Module performance | |
| Chip | BG11XX |
| Receiver type | GPS/QZSS:L1C/A & L5 GLONASS:L1 Galileo:E1 & E5a |
| Arithmetic | Integrate RTK algorithm |
| Agreement | NMEA-0183 or custom GALILEO L1 open service (with upgrade) Default:GGA,GSA,GSV,RMC Support:VTG,GLL,TXT ublox binary and NMEA Command |
| NMEA messages | RMC,VTG,GGA,GSA,GSV,GLL |
| Available baud rate | 4800bps~921600bps(default 115200bps) |
| Channel | 128 |
| Sensitivity | Tracking:-167dBm Capture:-158dBm Cold start-148dBm |
| Cold start | Average28秒 |
| Hot start | Average1秒 |
| Accuracy | Level 1cm+1ppm CEP50；Elevation 2cm+1ppm CEP50 Timepulse signal: RMS 30 ns |
| Max Height | 18000m |
| Max Speed | 515 m/s |
| Max Acceleration | ≦ 4G |
| Regeneration | 0.25-10 Hz |
| Positioning mode | |
| Compass | 5883P |
| Connector | |
| Connector | 6PIN 1.0mm JST |
| Physical property | |
| Type | |
| Power supply | |
| Voltage | 1.8V~3.3V |
| Power Consume | operational mode:103mW@1.8V, standby mode:＜20μW energy-saving mode: search:38mA, trace: 29mA power saving mode: ＜10mA |
| Oerating Environment | |
| Humidity range | 5% to 95% non-condensing |
| Working Temperature | -40℃ to 85℃ |
| Storage Temperature | -40℃ to 85℃ |
